Log Periodic Antenna 8dBi Typ. Gain, 0.3-2GHz Frequency Range RM-LPA032-8
Specifications RM-LPA032-8 Parameters Specifications Units Frequency Range 0.3-2 GHz Gain 8 Typ. dBi VSWR 1.4 Typ. Polarization Linear-polarized 3dB Beamwidth E plane: 53.78 H plane: 102.82 ° Connector N-Female Size(L*W*H) 873.6*855.6*2.441(±5) mm Weight 0.716 Kg Power Handing,CW 300 W Power Handing,Peak 500 W -
Log Periodic Antenna 6dBi Typ. Gain, 0.2-2GHz Frequency Range RM-LPA022-6
RF MISO’s Model RM-LPA022-6 is log periodic antenna that operates from 0.2 to 2 GHz, The antenna offers 6dBi typical gain. The antenna VSWR is ≤2 Typ. The antenna RF ports are N-50K connector. The antenna can be widely used in EMI detection, orientation, reconnaissance, antenna gain and pattern measurement and other application fields.
-
Log Periodic Antenna 6dBi Typ. Gain, 0.03-3GHz Frequency Range RM-LPA0033-6
RF MISO’s Model RM-LPA0033-6 is log periodic antenna that operates from 0.03 to 3 GHz, The antenna offers 6dBi typical gain. The antenna VSWR is less than 2:1. The antenna RF ports are N-Female connector. The antenna can be widely used in EMI detection, orientation, reconnaissance, antenna gain and pattern measurement and other application fields.
-
Log Periodic Antenna 7dBi Typ. Gain, 1-6GHz Frequency Range RM-LPA16-7
RF MISO’s Model RM-LPA16-7 is log periodic antenna that operates from 1 to 6 GHz, The antenna offers 7dBi typical gain. The antenna VSWR is 1.4Typ. The antenna RF ports are N-Female connector. The antenna can be widely used in EMI detection, orientation, reconnaissance, antenna gain and pattern measurement and other application fields.
-
Log Periodic Antenna 7dBi Typ. Gain, 0.25-4GHz Frequency Range RM-LPA0254-7
RF MISO’s Model RM-LPA0254-7 is log periodic antenna that operates from 0.25 to 4 GHz, The antenna offers 7dBi typical gain. The antenna VSWR is 1.5Typ. The antenna RF ports are N-Female connector. The antenna can be widely used in EMI detection, orientation, reconnaissance, antenna gain and pattern measurement and other application fields.
-
log periodic antenna 6 dBi Typ. Gain, 0.5-8 GHz Frequency Range RM-LPA058-6
RF MISO’s Model RM-LPA058-6 is log periodic antenna that operates from 0.5 to 8 GHz, The antenna offers 6 dBi typical gain. The antenna VSWR is less than 2. The antenna RF ports are N-Female connector. The antenna can be widely used in EMI detection, orientation, reconnaissance, antenna gain and pattern measurement and other application fields.
-
Log Periodic Antenna 7dBi Typ. Gain, 0.5-4GHz Frequency Range RM-LPA054-7
RF MISO’s Model RM-LPA054-7 is log periodic antenna that operates from 0.5 to 4 GHz, The antenna offers 7dBi typical gain. The antenna VSWR is 1.5 Typ. The antenna RF ports are N-Female connector. The antenna can be widely used in EMI detection, orientation, reconnaissance, antenna gain and pattern measurement and other application fields.
-
Log Periodic Antenna 6dBi Typ. Gain, 0.5-3GHz Frequency Range Model RM-LPA053-6
RF MISO’s Model RM-LPA053-6 is log periodic antenna that operates from 0.5 to 3 GHz, The antenna offers 6dBi typical gain. The antenna VSWR is less than 1.5:1. The antenna RF ports are N-Female connector. The antenna can be widely used in EMI detection, orientation, reconnaissance, antenna gain and pattern measurement and other application fields.
-
log periodic antenna 7 dBi Typ. Gain, 0.5-2 GHz Frequency Range RM-LPA052-7
RF MISO’s Model RM-LPA052-7 is log periodic antenna that operates from 0.5 to 2 GHz, The antenna offers 7 dBi typical gain. The antenna VSWR is less than 1.5. The antenna RF ports are N-Female connector. The antenna can be widely used in EMI detection, orientation, reconnaissance, antenna gain and pattern measurement and other application fields.
-
log periodic antenna 6 dBi Typ. Gain, 0.4-3 GHz Frequency Range RM-LPA043-6
RF MISO’s Model RM-LPA043-6 is log periodic antenna that operates from 0.4 to 3 GHz, The antenna offers 6 dBi typical gain. The antenna VSWR is less than 1.5. The antenna RF ports are N-Female connector. The antenna can be widely used in EMI detection, orientation, reconnaissance, antenna gain and pattern measurement and other application fields.
-
Log Periodic Antenna 6.5dBi Typ. Gain, 0.1-2GHz Frequency Range RM-LPA012-6
Specifications RM-LPA012-6 Parameters Specifications Units Frequency Range 0.1-2 GHz Gain 6 Typ. dBi VSWR 1.2 Typ. Polarization Linear-polarized Size 1503.5*1464.5 (±5) mm -
log periodic antenna 6 dBi Typ. Gain, 0.4-2 GHz Frequency Range RM-LPA042-6
RF MISO’s Model RM-LPA042-6 is log periodic antenna that operates from 0.4 to 2 GHz, The antenna offers 6dBi typical gain. The antenna VSWR is less than 1.7. The antenna RF ports are N-50K connector. The antenna can be widely used in EMI detection, orientation, reconnaissance, antenna gain and pattern measurement and other application fields.
