Circular Polarization Corrugated Horn Antennas

Available from 1 to 500GHz

RF Miso Standard gain horn antennas adopt linear polarization, providing an efficient andeconomical method for measurement These horn antennas can be widely used in EMIdetection, orientation, reconnaissance, antenna gain and pattern measurement and otherapplications. This series of horn antennas has the characteristics of high gain, Iow VswR, and lightappearance.

Note : Connectors can be matched according to your needs, please contact RF Miso

Table list view
Grid view

Model	Frequency,min.(GHz)	Frequency,max.(GHz)	Gain,Typ.(dBi)	Polarization	3dB Beamwidth, E-Plane(Deg.)	3dB Beamwidth,H-Plane(Deg.)	VSWR,Typ.	Cross Pol. Isolation,Typ. (dB)	Interface	LINK
RM-CGHA75-20	10	15	20	LHCP	12.9~19.8	12.7~19.7	<1.3	/	/
