Bi-conical Antenna 4 dBi Typ. Gain, 2-18GHz Frequency Range RM-BCA218-4
RF MISO’s Model RM-BCA218-4 is a vertical linear polarized biconical antenna that operates from 2-18GHz. The antenna offers a gain 4 dBi Typ. and low VSWR 1.5:1 with SMA-KFD connector. It designed for EMC, reconnaissance, orientation, remote sensing, and flush mounted vehicle applications. These helical antennas can be used as separate antenna components or as feeders for reflector satellite antennas.
-
Biconical Antenna 2 dBi Typ. Gain, 8-12 GHz Frequency Range RM-BCA812-2
Specifications RM-BCA812-2 Parameters Typical Units Frequency Range 8-12 GHz Gain 2 Typ. dBi VSWR 1.4 Typ. Polarization Linear-polarized Cross polarization >35 dB Connector 2.92mm-Female Material Al Size Φ42*58 mm Weight 0.056 Kg Power Handling,CW 10 W Power Handling,Peak 20 W -
Bi-conical Antenna 4 dBi Typ. Gain, 24-28GHz Frequency Range RM-BCA2428-4
Specifications RM-BCA2428-4 Item Specification Units Frequency Range 24-28 GHz Gain 4 Typ. dBi VSWR 1.3 Typ. Polarization Mode Linear Cross Polarization >35 dB Connector 2.92-KFD Finishing Paint Material Al dB Size About ø26*27.1 mm Weight 0.106 kg -
Bi-conical Antenna 4 dBi Typ. Gain, 0.8-2GHz Frequency Range RM-BCA082-4
Specifications RM-BCA082-4 Item Specification Units Frequency Range 0.8-2 GHz Gain 4 Typ. dBi VSWR 1.5 Typ. Polarization Mode Linear Connector SMA-Female Finishing Paint Material Al dB Size About ø216*123.5 mm Weight 2.694 kg -
Ka band Omni-Directional Antenna 4 dBi Typ. Gain, 17-30GHz Frequency Range RM-BCA1730-4
Specifications RM-BCA1730-4 Item Specification Units Frequency Range 17-30 GHz Gain 4 Typ. dBi VSWR 1.2 Typ. Polarization Vertical Connector N Female Size(L*W*H) Ø52*62(±5) mm Weight About 0.044 kg -
Ku band Omni-Directional Antenna 4 dBi Typ. Gain, 10.7-14.5GHz Frequency Range RM-BCA107145-4
Specifications RM-BCA107145-4 Item Specification Units Frequency Range 10.7-14.5 GHz Gain 4 Typ. dBi VSWR 1.2 Typ. Polarization Vertical Connector N Female Size(L*W*H) Ø76*71(±5) mm Weight About 0.157 kg -
Bi-Conical Antenna 3 dBi Typ. Gain, 35-37 GHz Frequency Range RM-BCA3537-3
l RF MISO’s Model RM-BCA3537-31 is a right-hand circular polarizatoin that operates from 35 to 37 GHz, The antenna offers horizontal Gain 3dBi Typ. The antenna RF ports are 2.92mm-F connector. The antenna can be widely used in EMI detection, orientation, reconnaissance, antenna gain and pattern measurement and other application fields.
-
Bi-conical Antenna 3 dBi Typ. Gain, 2-45GHz Frequency Range RM-BCA245-3
Specifications RM-BCA245-3 Item Specification Units Frequency Range 2-45 GHz Gain 3 Typ. dBi VSWR 1.5 Typ. Polarization Mode Linear Connector 2.4-Female Finishing Paint Material Al Size About ø58*84 mm Weight 0.198 kg Power Handling, CW 10 W -
Biconical Antenna -70 dBi Typ. Gain, 8-12 GHz Frequency Range RM-BCA812-70
Specifications RM-BCA812-70 Parameters Typical Units Frequency Range 8-12 GHz Gain -70 Typ. dBi VSWR 2 Typ. Polarization Linear-polarized Cross polarization >35 dB Connector N-Female Material Al Size Φ106*64.5 mm Weight 0.319 Kg Power Handling,CW 300 W Power Handling,Peak 500 W -
Biconical Antenna 1-20 GHz Frequency Range 2 dBi Typ. Gain, Slant polarization RM-BCA120-2
RF MISO’s Model RM-BCA120-2 is a slant polarization biconical antenna that operates from 1-20GHz. The antenna offers a gain 2 dBi Typ. and low VSWR 1.5:1 with SMA-Female connector. The use of foam covers between the outer polarization layers can effectively reduce the wind resistance on the antenna surface, especially in outdoor applications, and improve the mechanical stability of the antenna.
-
Biconical Antenna 1-8 GHz Frequency Range 2 dBi Typ. Gain RM-BCA18-2
RF MISO’s Model RM-BCA18-2 is a linear polarization biconical antenna that operates from 1-8GHz. The antenna offers a gain 2 dBi Typ. and low VSWR 1.5:1 with SMA-Female connector. It covers L, S, and C bands, suitable for multi-band scenarios.
